Magnetic Power Supply

  • Specialized Magnetic Track Power Supply: Designed specifically for hidden installation inside magnetic tracks, compatible with 48V LED strip systems.
  • Stable & Efficient Output: Features a wide input voltage range (180-265V 50/60Hz) and stable 48V output to ensure consistent lighting performance.
  • Space-Saving Ultra-Thin Design: Compact profile (available in standard and ultra-slim 16mm heights) fits perfectly into tight track spaces without bulging.
  • Reliable Power Performance: Available in “Full Power” models (100W/150W/200W) for heavy-duty use, and high-efficiency “80% Load” models for cost-effective, low-heat operation.
  • 3-Year Warranty: Built with high-quality materials and multiple safety protections (overload, short-circuit). Backed by our 3-year manufacturer warranty.
Power Consumption
–

Cutting Interval

–

Voltage

PCB Width

–

LED Density

–

Luminous Flux

–
View Datasheet
Request Quote
CE

CE Certified

RoHS

RoHS Compliant

High CRI

3 Year

Warranty

IP65/67/68

Options

Flexible PCB

Bendable

Voltage

Product Options

Colour Temperature
2700K
3000K
3500K
4000K
5000K
6000K
Wattage
4.8W/m
9.6W/m
14.4W/m

Custom Wattage Available

Lumens
220 lm/m
1650 lm/m
Type
CRI

LED/M

CCT
IP
Cutting
Lumen (lm/m)
Power
Width
Downloads

Professional Magnetic Track Power Supply Series

Optimize your lighting projects with CZINELIGHT’s range of magnetic track power supplies. Engineered for seamless integration, our power supplies deliver stable 48V power directly inside the track, eliminating the need for bulky external drivers. Whether you need the ultra-slim profile of our 16mini series or the high output of our 200W model, we have a reliable solution for your commercial or residential lighting needs.

Key Features

  • True Power Output: Our “Full Power” models deliver the rated wattage consistently, ensuring your LED strips run at full brightness without flickering.
  • Universal Compatibility: Supports a wide AC input voltage (180-265V), making it suitable for various global power grids.
  • Hidden & Aesthetic: The compact design allows the power supply to be completely hidden within the track, maintaining a clean, minimalist look.
  • Robust Safety: Equipped with over-voltage, over-current, and short-circuit protection to safeguard your lighting investment.

Technical Specifications

Model / TypePower RatingOutput VoltageProduct Size (mm)Best For
Premium Series (100W)100W (Full Power)48V220*58*25Standard magnetic tracks
Premium Series (200W)200W (Full Power)48V300*60*25Long-distance track runs
Upgraded Series (100W)100W (Full Power)48V220*58*25High-performance needs
16mini Series (100W)100W (80% Load)48V345*16*18Ultra-narrow tracks / Light loads
16mini Series (150W)150W (Full Power)48V345*16*18Ultra-narrow tracks / Heavy loads

Package & Support

  • Warranty: 3-Year Manufacturer Warranty.
  • Packaging: Securely packed in bulk cartons (40-50 units per carton, depending on the model).
  • Application: Ideal for magnetic track lights, LED strip lights, and linear lighting systems in retail stores, galleries, and modern homes.
